DH30
Pluggable∣highly stable∣ different structures
Video Introduction >>
Scroll
Description:
Agrade’s Industrial IDE Flash Module, DH30 series, is based on FLASH memory controller technology equipped with NAND FLASH memory. DH30 standard 44 pins with power input as 2.5” IDE storage disk interface. This DH30 series also provides standard Security and SMART functions that can allow the host system with versatile implementations for risk control or life DH30-an management in advance.
Features:
High reliability, low power consumption
Comply with PATA&IDE (ATA) interface specification
P/E：SLC(60000) MLC(3000)
Master / Slave Switch
Advanced Wear Leveling and Error Checking and Correction
Detailed introduction
download PDF
Video Introduction
| Product Name | iDiskOnModule(DOM) |
| model | DH30 |
| capacity | SLC：128M~16GB MLC：4GB~64GB |
| feature | * 高可靠性 * 符合PATA&IDE (ATA)接口规范 * 重复循环檫写次数：SLC(60000)，MLC(6000) * 主从盘转换开关 * 损耗平衡功能(Wear Leveling)和错误检查纠正技术(ECC) |
| Shock/vibration | 1500/20 |
| MTBF(h) | 2,000,000 |
| Working Voltage | 5.0V |
| Operating Temperature | 常温：0℃~70℃ 宽温：-40℃~85℃ |
| Storage temperature | -55℃~95℃ |
| Maximum read and write speed | 读取速度：64MB/S 写入速度：48MB/S |
| Overall dimensions | 48.4mm(L)×27.3mm(W)×5.8mm(H) |
