UD23
High performance and reliability
Video Introduction >>
Scroll
Description:
Agrade USB DOM is a high-performance 2.0 specification, supports USB mass storage command protocol, and supports high-speed, full-speed and low-speed transmission methods.
There are two form-factors available, to satisfy various compact applications.
*Vertical Standard (VS) type with 2.00mm pin pitch USB connector;
*Vertical Standard (VS) type with 2.54mm pin pitch USB connector.
Features:
External hardware write protection
USB2.0/1.1 Specifications
Standard USB port(10pin)
P/E：SLC(60000) MLC(3000)
Detailed introduction
download PDF
Video Introduction
| Product Name | USB DOM |
| series | Reliable Serirs |
| model | UD23 |
| capacity | SLC：128M~32GB |
| MLC：4GB~128GB | |
| feature | * 外部硬件写保护功能 |
| * USB2.0/1.1规范 | |
| * 标准USB接口(10pin) | |
| * 重复循环檫写次数：SLC(60000),MLC(6000) | |
| Shock/vibration | 1500/20 |
| MTBF(h) | 2,000,000 |
| Working Voltage | 5.0V/3.3V |
| Operating Temperature | 常温：0℃~70℃ 宽温：-40℃~85℃ |
| Storage temperature | -55℃~95℃ |
| Maximum read and write speed | 读取速度：60MB/S 写入速度：32MB/S |
| Overall dimensions | 35.5mm(L)×22.0mm(W)×6.6mm(H) |
